- The plug valve body all adopt high quality high strength steel alloy Specifications are 2 ",3 "rated working pressure 42MPA,70MPA,105MPA(6000PSI,10000PSI,15000PSI) three grades .Both ends can be connected by king connection or internal and external thread (LP/TBG) connection.All specifications are manufactured in strict accordance with American API standards, and can provide plug valves for use in normal temperature, low temperature and acidic environments.
- Material:(Valve body, plug) alloy steel, stainless steel, carbon steel
- Connection Ways:
- Plug Valve-union Connection:
- Type of Connection: FIG602(M×F)FG1002(M×F) FIG1502(M×F) FG1502(M×F)
- Actuator: Manualoperation、Pneumatic operation、Hydraulic operation、Turbine rod
- Plug Valve -threaded Connection:
- Type of Connection: 2"LP male screw、3"LP internal screw、2"TBG internal screw
- Actuator:Manual operation
Design Features:
- The maintenance and maintenance of the valve body does not need to be removed
from the pipeline, and special tools are not required when dismantling, and online
maintenance can be achieved
- Special coating process is adopted to make the wear resistance and corrosio resistance excellent
● Clear switch identification and limit mechanism
● A variety of opening devices for choice
● Has a low torque performance,flexible operation of portable
● Special sealing grease has dual functions of lubrication and sealing
Technical Date:
- Working pressure:42MPa-105MPa
- Nominal diameter:2”-3”
- Working temperature:-29℃-121℃(PU level)
The suitable operating mode: Standard, low humidity and H, S conditions
Precision Alloy Construction for High Pressure IntegrityThe High‑Pressure Plug Valve utilizes a high‑strength alloy steel body and complies with strict American API standards. Rated for working pressures of 42 MPa, 70 MPa, and 105 MPa (6 000 PSI, 10 000 PSI, 15 000 PSI), this component delivers exceptional resilience under high-pressure conditions. Both ends support king connection, internal thread, and external thread (LP/TBG) options, ensuring compatibility with various integral joints and high‑pressure pup joints systems.API‑Standard Reliable Performance Across EnvironmentsDesigned for use across a wide range of operating environments, these plug valves are suitable for normal temperature, low temperature, and acidic conditions. Adhering to API standards ensures dependable functionality and durable performance in critical industrial and oilfield operations where swivel joints, adjustable joints, and similar components are deployed.Versatile Integration for Diverse Flow AssembliesExwell’s High‑Pressure Plug Valve accommodates multiple connection methods—king connection and internal/external thread—providing seamless integration into existing fluid distribution systems. Its API‑compliant design facilitates interchangeability with other spare parts such as customed swivel joints, high‑pressure pup joints, and integral joints, enhancing system modularity and simplifying maintenance.Product AdvantagesAlloy Steel Strength for High‑Pressure DurabilityConstructed from high-strength alloy steel, this High‑Pressure Plug Valve withstands extreme pressure ratings (up to 105 MPa), delivering superior durability and longevity in tough industrial applications.Flexible Connection Configurations for System CompatibilityFeaturing king connection as well as internal and external thread (LP/TBG) ends, this valve ensures compatibility with diverse field setups and simplifies integration into existing systems.API‑Compliant Trust and Environmental AdaptabilityManufactured to meet American API standards, this plug valve offers reliable performance in normal, low‑temperature, and acidic environments, making it a dependable component alongside swivel joints, integral joints, and adjustable joints in fluid control assemblies.
About UsAnhui Exwell New Energy Technology Co., Ltd. (Exwell) is a dedicated enterprise combining research, manufacturing, and sales of oil drilling equipment—including integral joints, swivel joints, high‑pressure pup joints, adjustable joints, and high‑pressure plug valves. With advanced processing facilities, qualified personnel, comprehensive testing methods, and a robust quality management framework, Exwell delivers reliable performance and product consistency.Committed to the principle “reputation first, customer first,” Exwell offers products that are 100% interchangeable with original components and customizable based on customer specifications.The company serves global markets with efficient support and aims to establish strong partnerships worldwide.Contact us today to request your durable High‑Pressure Plug Valve and enhance system performance in demanding flow systems.FAQWhat pressure ratings are available for the High‑Pressure Plug Valve?It is available in 42 MPa, 70 MPa, and 105 MPa ratings (6 000 PSI, 10 000 PSI, 15 000 PSI).What connection types can be applied to this valve?Both king connection and internal/external thread (LP/TBG) ends are offered to fit diverse system configurations .Does this valve meet industry standards for varied conditions?Yes, it is manufactured according to American API standards and is suitable for normal, low-temperature, and acidic environments.Can this valve be integrated with swivel joints or adjustable joints?Yes, the valve’s API compliance and flexible connections allow it to work effectively with other components like swivel joints, integral joints, and adjustable joints.Is customization available for specific project needs?While the site confirms API-standard production, Exwell also offers customization of components based on customer-provided specifications.
